POMILUCK® P FCCL
Base Film : Taimide TP PI Film
PI Color : Yellow , Semitransparent
PI Thickness : 12.5μm, 25μm
Cu Thickness : 0.2μm~8μm
FCCL Composition : Single / Double Sided
POMILUCK®P 系列產品除了具備有N系列的高接著力與尺寸安定性佳等特色之外，還增加了高光學對比的特性，可以適用於現有的AOI與AVI的檢驗設備，一般線路至細線路皆可適用，經濟實用
 |
 |
 |
 |
高接著力
(High peel strength) |
低粗糙度
(Low profile of interface) |
可預鑽孔
(Pre-drill can be achieved) |
高光學對比
(High contrast for optical inspection) |
| Product |
Transmittance (%) |
Haze (%) |
AOI image |
| N2522 |
60 |
2
|
 |
| P2522 |
65 |
70 |
 |
- 細線化/薄型化軟板 (Fine pitch & thinner FPCs)
- COF 載板 (2 metal COF for driver ICs)
